Product Overview
Select Wastewater Treatment System
PRODUCT NAME
ZLD 10
CAPACITY
13500 m3/year
ENERGY CONSUMPTION
20-30 kWh/m3
DIMENSIONS: L X H X B
5320 x 3925 x 2970 mm
WEIGHT*
8000 kg
*Weight is indicative
PRODUCT NAME
ZLD 7
CAPACITY
6750 m3/year
ENERGY CONSUMPTION
25-35 kWh/m3
DIMENSIONS: L X H X B
4030 x 3152 x 2330 mm
WEIGHT*
6500 kg
*Weight is indicative
PRODUCT NAME
ZLD 6
CAPACITY
5400 m3/year
ENERGY CONSUMPTION
30-40 kWh/m3
DIMENSIONS: L X H X B
3500 x 3090x 2230 mm
WEIGHT*
4700 kg
*Weight is indicative
PRODUCT NAME
ZLD 5
CAPACITY
3750 m3/year
ENERGY CONSUMPTION
35-45 kWh/m3
DIMENSIONS: L X H X B
3500 x 3090 x 2230 mm
WEIGHT*
3800 kg
*Weight is indicative
PRODUCT NAME
ZLD 4
CAPACITY
3000 m3/year
ENERGY CONSUMPTION
40-50 kWh/m3
DIMENSIONS: L X H X B
3120 x 3060 x 2130 mm
WEIGHT*
2400 kg
*Weight is indicative
PRODUCT NAME
ZLD 3
CAPACITY
2250 m3/year
ENERGY CONSUMPTION
45-55 kWh/m3
DIMENSIONS: L X H X B
3120 x 3060 x 2130 mm
WEIGHT*
2100 kg
*Weight is indicative
PRODUCT NAME
ZLD 2
CAPACITY
1500 m3/year
ENERGY CONSUMPTION
50-60 kWh/m3
DIMENSIONS: L X H X B
2210 x 2720 x 1270 mm
WEIGHT*
1850 kg
*Weight is indicative
PRODUCT NAME
ZLD 1
CAPACITY
1750 m3/year
ENERGY CONSUMPTION
55-65 kWh/m3
DIMENSIONS: L X H X B
2210 x 2720 x 1270 mm
WEIGHT*
1550 kg
*Weight is indicative
PRODUCT NAME
ZLD 0.5
CAPACITY
450 m3/year
ENERGY CONSUMPTION
60-70 kWh/m3
DIMENSIONS: L X H X B
1720 x 2120x 1005 mm
WEIGHT*
950 kg
*Weight is indicative
Take Control of Your Wastewater Costs
Since the beginning of the year, many companies have felt the impact of rising costs associated with the disposal of industrial wastewater. We offer two flexible solutions that can be tailored to your needs:
- On-site wastewater solution– A complete evaporation system installed directly at your facility. Here, the wastewater can be treated and reused in your production, reducing costs and minimizing reliance on external disposal.
- Treatment at our wastewater facility in Grindsted– You send us your wastewater, and we handle the entire treatment process at our newly established and modern wastewater plant.
Whichever solution you choose, we can help you reduce wastewater volume, lower costs, and achieve a high degree of reuse.
The Complete ENVOTHERM Solution
At ENVOTHERM, we offer customized wastewater solutions for a wide range of industries and sectors. Our expertise spans everything from energy and waste management to food production, the pharmaceutical industry, and much more. We work closely with our customers to understand their unique needs and deliver effective, long-lasting solutions that support their operations and future growth.
Our solutions can be adapted to many other industries, and we are always ready to meet new challenges and needs. No matter which sector you are in, we can help optimize your processes and ensure you get the best possible solution. Under “Industries,” you will find a selection of the sectors we have provided solutions for – also see our case studies for further insight.
1. Pre-filtration and pH Adjustment
- The wastewater first passes through a belt filter or pre-filter to remove impurities and solid particles.
- After pre-filtration, the pH level is adjusted to optimize the subsequent treatment process.
2. Wastewater Treatment System – The EVR Method
- ENVOTHERM’s advanced evaporation technology ensures highly efficient wastewater treatment.
- With low energy consumption, the process water is converted into pure distillate, which can be reused in production.
- The evaporation system minimizes the amount of waste and thus significantly reduces disposal costs.
3. Activated carbon filter – ensuring purity
- This step removes remaining organic compounds and ensures that the treated water meets the highest quality standards.
- After evaporation, an activated carbon filter is recommended to remove any unwanted odors or trace substances.
